Backwards Trapezoidal Flume in Manhole

> Gallery
A Small Trapezoidal Flume Installed Backwards in a Manhole

A Small Trapezoidal Flume Installed Backwards in a Manhole

Description

A Small 60 Degree Trapezoidal Flume installed backwards in a manhole.  You can tell the flume is backwards by the staff gauge and base for the ultrasonic mounting bracket being downstream (flow is from bottom-to-top in this photo).

The flume is used to measure treated industrial discharge.
