Elevated Runoff Measuring Trapezoidal Flume

Elevated Runoff Measuring Trapezoidal Flume

  • : USDA-ARS

Description

An elevated fiberglass Trapezodial Flume used to measure runoff.  The flume has improvised support structures to allow it to be installed level on the hill slope.

Flow is pipe directly into the flume via a bulkhead on the inlet of the flume.  For greatest accuracy an end adapter should be used to allow the flow to transition from the round pipe into the v-shaped cross-section of the flume.
